Nikon Z7 Review: Autofocus Performance
Although the Nikon Z7 sports a completely new 493-point autofocus system, it still shares a lot of focusing DNA with Nikon’s DSLR lineup. Nikon DSLRs, especially the newest models, are known for their high-quality phase-detect autofocus systems when shooting via the viewfinder. But that reputation doesn’t carry over to live view autofocus performance, which, even on Nikon’s best DSLRs is quite slow.
The Z7’s autofocus is a bit of a blend between Nikon’s traditional viewfinder and live view focusing systems, although it bears more similarities to the live view implementation. The addition of on-sensor phase-detect pixels lets the Z7 focus quite quickly, and other features like subject tracking and Low-Light AF are far better than Nikon’s previous live view attempts.
Although one could argue that the autofocus system on the Z7 is inferior in AF speed and accuracy to Nikon’s 153-point phase-detection AF found on cameras like the Nikon D500 and D850, some of the AF features of the Z7 are game-changing for Nikon.
With Nikon adding automatic eye and animal detection autofocus features into the firmware (more on these features below), the Nikon Z7 now stands out from all DSLRs in its ability to continuously track subject eyes, something no Nikon DSLR has been previously able to do. Eye detection features are great in the field because they allow photographers to actively engage with their subject while letting the camera do its job with keeping the subject continuously in focus.
Nikon has also completely changed the way subject-tracking AF works on the Z7 with firmware 3.30. Once updated, it is now possible to configure one of the function buttons to engage the subject-tracking mode with a single press of a button. Holding the AF-ON (or whichever button is programmed to focus) will lock on the subject and actively track it.
If we were to compare all the AF features of the Nikon D850 vs the Nikon Z7, here is what they look like:
|AF Area Mode||Nikon D850||Nikon Z7|
|Pinpoint||Yes (in live view only)||Yes|
|9-Point Dynamic Area||Yes||Yes|
|25-Point Dynamic Area||Yes||No|
|72-Point Dynamic Area||Yes||No|
|153-Point Dynamic Area||Yes||No|
|Wide-Area AF||Yes, one size (and live view only)||Yes, both L and S sizes|
|3D Tracking||Yes||Yes, in Auto Area AF|
|Eye AF||No||Yes, Firmware > 2.00 and beyond|
|Animal Detection AF||No||Yes, Firmware > 3.00 and beyond|
As you can see, while the Nikon D850 has more complex autofocus tracking algorithms, including Group Area AF, the Nikon Z7 is capable of performing Eye and Animal Detection autofocus, which the D850 cannot do, even when shooting in live view mode.
The Nikon Z7 doesn’t have a dedicated button to change autofocus settings. This is a departure from Nikon’s classic design choice, to have an AF-M switch on the front of the camera with an autofocus button inside. In its place, Nikon expects you to use the quick menu – accessed via the “i” button – to change focusing settings, or otherwise assign a custom button for that purpose.
Personally, I’ve chosen to assign my movie record button to change autofocus settings, and it’s not a bad solution. Press the button and spin one dial to change between AF-S, AF-C, and MF. Spin the other dial to change autofocus area modes, such as Auto Area, 9-Point Dynamic Area, Wide Area, Pinpoint (only in AF-S), and so on. Of note is that the Z7 does not have an AF-A mode to switch automatically between AF-S and AF-C, which is not a big deal for most of this camera’s users, but nonetheless matters to some photographers.
Once you assign autofocus settings to a good custom button, you’ll find that the Z7 works in much the same way as other Nikon cameras. Of course, assigning a button for this purpose does prevent you from using it for a different custom function, which isn’t ideal. As mentioned earlier, this takes away a spot to assign something like metering or bracketing. Still, if you change autofocus settings frequently, assigning a custom button is much better than entering the “i” menu all the time.
Lastly, note that you cannot use the Z7’s LCD touchscreen to control your autofocus point while looking through the viewfinder. Other mirrorless cameras have this capability, and some photographers have noted it to be a useful part of their shooting styles. Personally, I prefer the joystick instead, and I wouldn’t use the touchscreen for this purpose even if it were available. But if this is a feature you think you would use, just keep in mind that the Z7 doesn’t have it – at least at the moment. A firmware update could conceivably add this capability.
AF-S Performance (Static Subjects)
The Z7’s autofocus is superb for static subjects, focusing quickly and accurately, including in low-light conditions. You’ll still want to find a subject with good texture, though, not just a single sharp line or soft transition. And, as covered more in a moment, you get the best performance using native Z lenses rather than F-mount lenses via the FTZ adapter.
With the native Z mount lenses, the Z7’s AF-S (single servo autofocus) is simply excellent and very accurate. In fact, when compared to DSLR performance with prime lenses, the focusing performance of the Nikon Z7 is superior for a number of reasons. First of all, unlike DSLR cameras that have a separate phase-detection autofocus system that does not always match the lens, mirrorless cameras focus right on the sensor plane. This basically eliminates focus variances between the camera body and the lens and removes the need for fine-tuning lenses.
Second, unlike DSLR cameras that require lenses to always focus at their widest apertures (to keep the viewfinder bright and to allow maximum light to reach the phase-detection system), which results in focus shift issues, the Nikon Z7 stops the lens down to the exact aperture before it focuses, which pretty much eliminates focus shift.
Electronic viewfinders and LCD screens are able to compensate for the reduced amount of light by boosting their brightness, something that is not possible to do on an optical viewfinder. It is important to note that the stopping down happens only at larger apertures that are prone to focus shift (from maximum aperture to f/5.6). When using smaller apertures like f/8-f/22, the camera keeps the lens locked at large enough aperture to pass sufficient light to the sensor, then stops the lens down to the desired aperture right before the image is captured. This is a very smart way of mitigating focus shift on the Z7, which drastically reduces focusing issues.
Lastly, I personally found the Nikon Z7 to focus extremely accurately on a high-contrast test target when using Imatest software, which was very impressive. When testing with a DSLR, although I can often count on the contrast-detection AF when using live view, it often fails with some lenses and I have to manually tweak focus afterward. With the Nikon Z7, I have not encountered a single case where I had to tweak focus – it was pretty much “dead-on” every single time. This made the process of evaluating lenses easier, although there were some big annoyances that I wish weren’t there, which I will cover in the next section below.
Overall, autofocus speed and accuracy are quite impressive, with practically no hunting for focus at all under most conditions, as shown in the earlier video. You have several autofocus area modes to choose from for AF-S, including a “Pinpoint” area mode previously found only on the D850 in live view. This is a great way to set an extremely small focusing box to lock onto a very precise subject. It takes a bit more time to autofocus when you use this method, so I personally prefer the slightly larger area mode by default, but this is a nice way to make sure that you are targeting your exact subject – for example, the center of a flower rather than its petals.
Face / Eye AF and Animal Detection AF
Since the Z7 was released, Nikon has updated the camera firmware a number of times. Since firmware 2.0, a new feature many Nikon shooters asked for became available: Eye Autofocus. Although it is Nikon’s first attempt at this feature, it works quite well for tracking the eyes of a subject at moderate distances.
In addition to Eye autofocus, Nikon has also introduced “Animal Detection” AF mode for tracking animals. When using the Area AF mode, Animal Detection AF automatically detects animals like dogs and cats, figures out where the nearest eye is, then it focuses on it. I found this feature to work really well for photographing my cats, who are always on the move.
Here is a video that details how Face / Eye AF and Animal Detection AF work on the Nikon Z7, as well as its low-light autofocus in indoor conditions:
So far, our assessment of Eye AF is quite positive. However, when shooting at close distances and when shooting tight headshots with telephoto lenses, the Eye AF algorithm seems to occasionally focus on the subject’s eyelashes instead of the eyes. Another problem is that when the subject is farther away, the Eye AF does not get activated until the subject gets close enough to the camera, as we have demonstrated in the above video.
When multiple subjects are in the frame, the camera allows switching between all the detected eyes of subjects. In addition, there is now no need to press the OK button to engage focus tracking (although area locking still works with the OK button). The Face Detection menu in “Custom Setting Menu” -> “Autofocus” now displays “Auto-area AF face/eye detection”, with “Face and eye detection on” by default. With the latest firmware 3.30, you will also be able to see the new “Animal detection” menu option:
Here is a test case scenario, where I photographed my daughter with the Nikon Z 50mm f/1.8 S lens at a fairly close distance:
Here is the resulting image:
And here is a 100% crop of the above image:
As you can see, the camera did well when focusing on her left eye in this case. This is the best-case scenario – other shots taken at different distances and angles showed slight inaccuracies in Eye AF precision, especially when the subject was constantly moving, which is normal.
Overall, the Z7 is excellent for stationary subjects. Especially if you already prefer shooting in live view, such as many architectural and landscape photographers, you’ll find the Z7’s AF-S to beat most other options on the market for focusing on a scene. It’s fast and accurate, and it has enough options to make autofocus easy even in tricky conditions.
AF-C Performance (Moving Subjects)
Although the Z7 does a great job at single-servo autofocus, continuous autofocus is more of a mixed bag. That’s especially true when you try to track your subject across the frame. Although it does a better job locking onto and following your subject than Nikon DSLRs in live view, it can sometimes miss focus in a series of AF-C images. Note that it is hardly the worst tracking performance for a mirrorless camera, and you definitely can get good photos shooting AF-C, but it still seems to lag behind Nikon DSLRs.
This is especially true in dark conditions since the low-light AF doesn’t engage in AF-C mode (and even if it did, it wouldn’t be nearly fast enough to keep up with a moving subject). You’ll need to switch back to AF-S if you want any chance of the camera locking on in dark environments.
Previous Nikon users might find another thing odd: In AF-C mode, the red box that indicates proper focus never turns green, even when the photo is completely sharp. Instead, it stays red and unchanging the entire time, unless the Z7 has completely failed to find focus, at which point the box starts blinking. Although this isn’t unworkable behavior, it’s a bit disconcerting if you’ve internalized that red means out of focus and green means tack-sharp.
As of firmware v3.30, the Nikon Z7 can be set up to initiate subject tracking via one of the function buttons on the camera, or on a lens (if it has one). Once that’s done, you have to make sure to switch to Auto Area AF mode in order to be able to use it. Pressing the function button will switch to subject tracking mode – all you have to do from there is press the AF-ON button (or whichever button is set up to focus) to start tracking the subject. To stop tracking or change the subject, you simply let go of the focus, which resets the box to the center of your frame.
Overall, we are happy to see Nikon implement so many changes to the autofocus capabilities of the Z7. While the autofocus system has not yet caught up with Nikon’s top-of-the-line DSLRs, it is just a matter of time until it does.
The new “low light AF” feature on the Z7 uses longer shutter speeds to gather more light, creating a brighter image preview in order to help the autofocus system lock on in dark environments. The downside is that it can take quite a bit of time to focus when using the low-light AF feature, and the image preview becomes quite laggy as a result of the longer shutter speeds. To me, those downsides don’t matter too much, because the low-light AF feature lets the Z7 shoot in much darker conditions than would otherwise be possible.
The Z7 focuses best on high-texture areas, so make sure to find subjects with as much contrast as possible when you want to use this feature. If you find a good subject, you’ll be able to use the Z7 in remarkably dark conditions to lock focus precisely. I took the photo below with an f/4 lens under moonlight and a bit of residual light from blue hour, autofocused on the texture in the hills – no problem with this camera:
In fact, I like the brighter preview so much that I wish you could use it while focusing manually, particularly for something like Milky Way photography. As good as the Z7’s low-light AF can be, it still won’t autofocus on a star in the dark of night. That’s no surprise, of course; I wouldn’t expect such insane performance, even though the Fuji X-T3 somehow manages to make it work. But I would love to have the brighter preview available for manual focus work, since it’s not easy to pinpoint a star at night based on the normal LCD image. This, too, could be added with a firmware update, and it would be a very welcome sight.
When adapting F-mount lenses onto the Z7 via the FTZ adapter, focus performance noticeably declines. Low-light AF doesn’t work in conditions that are quite as dark, for one. And you’ll find the Z7 giving up more quickly in general, regardless of lighting conditions. You need to be more careful about your subject and find something with as much contrast as possible. Accuracy stays quite high when it does lock on, though.
It’s not actively bad, and it certainly succeeds more than it fails, but at the same time, you can tell that the Z7 was made for native lenses. Even the speed of focusing is slower with the FTZ adapter compared to the fly-by-wire system in Z lenses. That wouldn’t be as big of a problem if more Z lenses were available, but at the moment the selection is quite limited. So, if you’re eager to make the Z7 your main camera system, you better be willing to accept the somewhat worse focusing performance with the FTZ adapter.
Again, I’ll emphasize that these issues are not going to ruin your day-to-day photography. The autofocus performance from the FTZ adapter is not vastly worse; it’s just a step-down. You can still get plenty of good photos from adapted lenses, generally without focusing issues at all. But if you tend to push against the boundaries of the Z7’s focus system anyway, you’ll run into problems sooner when you adapt a lens.
Is the Nikon Z7 Autofocus Good Enough?
Let’s say you’re a D850 shooter, and a group of Nikon engineers offers to build you a better version of live view autofocus. It’s noticeably faster, offers eye autofocus, adds some extra tracking options, and works in lower light than before. But these improvements come at a cost: the only way to implement the new version of live view is to scrap the old, highly praised viewfinder autofocus system. For better or worse, both in live view and the viewfinder, you’re stuck with the new focusing system. Would you make the swap? Because that’s about where the Z7 is.
It’s not a scenario that many photographers would openly embrace, although I’ll caution that it’s not as bad as you might think. After-all, a significant number of landscape and architectural photographers are using live view for most photos anyway. With this change, your live view autofocus system is more responsive overall, and it works better in low-light conditions. Perhaps that’s more important to you than the advantages of the old viewfinder autofocus system. Similarly, video shooters should welcome better tracking for moving subjects, improving the camera’s usability by a significant degree.
Portrait, travel and pet photographers will most likely happily embrace the new Eye and Animal Detection autofocus features that have been rolled out via firmware. The ability to track subjects’ eyes is an important one – the camera automatically finds the subject and often does a decent job with accurately focusing on the subject’s face or their eyes. While eye autofocus has not yet reached extremely high accuracy levels with the latest firmware, it works reasonably well – arguably better and faster than manually moving the focus point in Single-Point AF.
It’s really the sports and wildlife photographers who should be cautious about moving to Nikon’s mirrorless system. Nikon’s 153-point phase-detection system on cameras like the Nikon D500 and D850 is excellent. Aside from the AF system on top-of-the-line cameras like Nikon D6 and Canon 1D X Mark III, it is one of the best autofocus systems on the market today for tracking fast action. So if that’s mostly what you do, you might want to hang on to your DSLR and wait until Nikon’s mirrorless AF system fully catches up. Plus, there are no super-telephoto lenses for the Nikon Z at the moment anyway…
Considering all the latest firmware improvements, the Nikon Z7 has clearly stepped up its autofocus performance in a number of ways. The introduction of eye and animal detection modes is clearly an indication of Nikon’s commitment to its mirrorless cameras, and we expect the company to continue tweaking these modes to make them faster and more accurate in the future.
Shooting Speed (FPS) and Buffer
The Nikon Z7 is capable of shooting at up to 9 frames per second when shooting in Continuous High (Extended) mode. Previously, there was a limitation that locked exposure after the first shot, but Nikon removed this limitation as of firmware 2.00. With files hovering around 44 MB with 12-bit lossless-compressed RAW file, 9 FPS is quite impressive for a 45 MP camera – that’s a lot of data to process.
Unfortunately, the Nikon Z7 buffer doesn’t do a great job keeping up with all this data. You’ll only get about 19 photos at 9 FPS shooting (totaling a bit over two seconds before the camera slows down). The newer Nikon Z7 II shows some improvements. Here is the full chart, comparing the Z7 to a number of other Nikon cameras today:
|Camera||Image Type||File Size||Buffer|
|Nikon Z7 II||NEF (RAW), Lossless compressed, 12-bit||45.7 MB||77|
|Nikon Z7||NEF (RAW), Lossless compressed, 12-bit||44.7 MB||23|
|Nikon Z6 II||NEF (RAW), Lossless compressed, 12-bit||TBD||124|
|Nikon Z6||NEF (RAW), Lossless compressed, 12-bit||22.5 MB||35|
|Nikon D850||NEF (RAW), Lossless compressed, 12-bit||41.5 MB||170|
|Nikon D810||NEF (RAW), Lossless compressed, 12-bit||31.9 MB||47|
|Nikon D800 / D800E||NEF (RAW), Lossless compressed, 12-bit||32.4 MB||21|
|Nikon D750||NEF (RAW), Lossless compressed, 12-bit||21.0 MB||25|
|Nikon D780||NEF (RAW), Lossless compressed, 12-bit||21.7 MB||100|
|Nikon Z7 II||NEF (RAW), Lossless compressed, 14-bit||57.0 MB||49|
|Nikon Z7||NEF (RAW), Lossless compressed, 14-bit||55.8 MB||19|
|Nikon Z6 II||NEF (RAW), Lossless compressed, 14-bit||TBD||TBD|
|Nikon Z6||NEF (RAW), Lossless compressed, 14-bit||28.2 MB||43|
|Nikon D850||NEF (RAW), Lossless compressed, 14-bit||51.5 MB||51|
|Nikon D810||NEF (RAW), Lossless compressed, 14-bit||40.7 MB||28|
|Nikon D800 / D800E||NEF (RAW), Lossless compressed, 14-bit||41.3 MB||17|
|Nikon D750||NEF (RAW), Lossless compressed, 14-bit||26.9 MB||15|
|Nikon D780||NEF (RAW), Lossless compressed, 14-bit||27.7 MB||68|
|Nikon Z7 II||NEF (RAW), Compressed, 12-bit||39.6 MB||96|
|Nikon Z7||NEF (RAW), Compressed, 12-bit||40.7 MB||23|
|Nikon Z6 II||NEF (RAW), Compressed, 12-bit||TBD||TBD|
|Nikon Z6||NEF (RAW), Compressed, 12-bit||20.4 MB||37|
|Nikon D850||NEF (RAW), Compressed, 12-bit||34.2 MB||200|
|Nikon D810||NEF (RAW), Compressed, 12-bit||29.2 MB||58|
|Nikon D800 / D800E||NEF (RAW), Compressed, 12-bit||29.0 MB||25|
|Nikon D750||NEF (RAW), Compressed, 12-bit||19.2 MB||33|
|Nikon D780||NEF (RAW), Compressed, 12-bit||19.4 MB||100|
|Nikon Z7 II||NEF (RAW), Compressed, 14-bit||49.2 MB||74|
|Nikon Z7||NEF (RAW), Compressed, 14-bit||49.4 MB||19|
|Nikon Z6 II||NEF (RAW), Compressed, 14-bit||TBD||TBD|
|Nikon Z6||NEF (RAW), Compressed, 14-bit||24.8 MB||43|
|Nikon D850||NEF (RAW), Compressed, 14-bit||43.8 MB||74|
|Nikon D810||NEF (RAW), Compressed, 14-bit||36.3 MB||35|
|Nikon D800 / D800E||NEF (RAW), Compressed, 14-bit||35.9 MB||20|
|Nikon D750||NEF (RAW), Compressed, 14-bit||23.9 MB||21|
|Nikon D780||NEF (RAW), Compressed, 14-bit||24.1 MB||100|
|Nikon Z7 II||JPEG Fine (Large)||24.0 MB||200|
|Nikon Z7||JPEG Fine (Large)||17.2 MB||25|
|Nikon Z6 II||JPEG Fine (Large)||TBD||200|
|Nikon Z6||JPEG Fine (Large)||9.4 MB||44|
|Nikon D850||JPEG Fine (Large)||22.0 MB||200|
|Nikon D810||JPEG Fine (Large)||18.1 MB||100|
|Nikon D800 / D800E||JPEG Fine (Large)||16.3 MB||100|
|Nikon D750||JPEG Fine (Large)||12.6 MB||100|
|Nikon D780||JPEG Fine (Large)||9.8 MB||100|
Note that some of these figures are based on our own measurements because Nikon does not always provide full buffer information. Your results may differ, especially if you use a slower memory card.
As we have already discussed on the first page of the review, compared to the D850, the Z7 clearly lags in buffer performance. For just one example, at 14-bit lossless compressed RAW, it’s a difference between 19 and 51 images before the camera slows down. The D850 looks even better by comparison when shooting 12-bit lossless compressed RAW, at which point it gets a whopping 170 images compared to the Z7’s 23 before slowing down.
The same can be said of the newer Nikon Z7 II, which also has a much higher buffer than the Z7. If you’re a full-time sports or wildlife photographer, you will most likely prefer one of the other cameras on this list over the Z7.
That said, there is some good news for Z7 shooters. Unlike some cameras, the Nikon Z7 doesn’t lock up completely when the buffer fills, and even continues around 3-4 FPS. So, although the buffer numbers aren’t very good, at least the Z7 doesn’t freeze up completely after a few seconds of continuous shooting.
One last thing to note is viewfinder blackout. Despite earlier reports to the contrary, the Z7 does not go completely dark when you shoot at fast frame rates. Instead, at 9 FPS, you’ll see a near-live preview of the scene, but with the viewfinder image only refreshed at 9 FPS. So, it’s jerky, but you’ll see the scene. At 8 FPS and slower, the viewfinder image will go black for a fraction of a second during individual frames, but the rest of the time will be live and quick to refresh – not too different from shooting with a DSLR when the mirror moves out of the way in mid burst. The key is that you need to turn ON “View all in continuous mode” in the Shooting/Display section of the Custom Setting Menu.
On the next page of this review, we’ll take a look at the Nikon Z lens lineup as well as the FTZ adapter for using existing DSLR lenses on the Z7.
