Lens Summary
Brand: Olympus
Also Known As: Olympus 8mm f/1.8 Fisheye
Lens Type: Prime Lens
Format: Micro Four Thirds
Focus: Autofocus
Lens Mount: Micro Four Thirds
Release Date: 2015-05-12
MSRP Price: $999.99
Made in: Japan
Production Status: Discontinued
Lens Description: The M.ZUIKO DIGITAL ED 8mm f/1.8 PRO Fisheye lens features a 180-degree diagonal angle of view and dustproof/splashproof construction for unlimited wide-angle adventure. The lens is also compatible with a custom dome port for use with an Olympus underwater housing. The lens has 17 elements in 15 groups and can capture high resolution at the very edges of an image, even at the maximum aperture of f/1.8. ZERO Coating minimizes optical flares and ghosting. The lens also comes with a fixed lens hood and a pinch-style lens cap LC-62.
Olympus M.Zuiko Digital ED 8mm f/1.8 Fisheye Pro Specifications
| Lens Specifications | |
|---|---|
| * Supplied accessories may differ depending on country or area | |
| Lens Type | Prime Lens |
| Focal Length | 8mm |
| Mount Type | Micro Four Thirds |
| Format | Micro Four Thirds |
| Compatible Format(s) | Micro Four Thirds |
| Compatible with Teleconverters | No |
| Maximum Reproduction Ratio | 0.20x |
| Image Stabilization | No |
| Aperture Information | |
| Aperture Ring | No |
| Maximim Aperture | f/1.8 |
| Minimum Aperture | f/22 |
| Maximum Angle of View (APS-C or smaller format) | 180° |
| Optical Information | |
| Lens Elements | 17 |
| Lens Groups | 15 |
| Diaphragm Blades | 7 (rounded) |
| Extra-Low Dispersion Glass Elements | 3 Super ED lenses, 2 ED lenses, 1 Super HR Lens, 2 HR lenses |
| Aspherical Elements | 1 |
| Focus Information | |
| Focus | Autofocus |
| Built-in Focus Motor | Yes |
| Silent Wave / UltraSonic Motor | Yes |
| Internal Focusing | Yes |
| Minimum Focus Distance | 0.12m |
| Filter Information | |
| Filter Size | 01/01/1900 |
| Accepts Filter Type | 01/01/1900 |
| Physical Characteristics | |
| Weather / Dust Sealing | Yes |
| Mount Material | Metal |
| Dimensions | 62mm ｘ 80mm |
| Weight | 315g |
| Other Information | |
| Available in Colors | Black |
| Supplied Accessories | Lens Cap (LC-62E), Lens Rear Cap (LR-2), Lens Case (LSC-0811-BLK) |
Lens Construction and MTF Chart
