Lens Summary
Brand: Fujifilm
Also Known As: Fuji 10-24mm f/4 OIS
Lens Type: Zoom Lens
Format: APS-C / DX
Focus: Autofocus
Lens Mount: Fujifilm X
Release Date: 2013-12-18
MSRP Price: $999.95
Made in: Japan
Production Status: In Production
Manufacturer Link: Product Page
Lens Description: Its ultra wide to standard focal length capabilities make it the perfect choice for shooting dynamic, high impact landscapes images with excellent detail from the foreground to the far distance. The maximum F4.0 aperture is available throughout the 2.4x zoom range. With 3.0 step (CIPA standards) Optical Image Stabilization, the ability to work handheld when shooting in low light is boosted. It offers high-speed AF thanks to an enhanced inner focusing system, and the use of a stepping motor and lightweight internal lenses has ensured that the XF10-24mm is very quiet to use. Its minimum working distance of 24cm means that with macro photography you can capture both the small foreground detail and the wider surroundings to give your subject greater context.
Photography Life Review Summary: The Fujifilm XF 10-24mm f/4 R OIS is a great ultra-wide angle zoom that produces consistently sharp and colorful images, and it is extremely light and portable, making it a great lens to travel light with. I have taken it with me all over the world, and it has delivered great results. Read the full Fujifilm XF 10-24mm f/4 R OIS Review by Photography Life.
Fujifilm XF 10-24mm f/4 R OIS Specifications
| Lens Specifications | |
|---|---|
| Lens Type | Zoom Lens |
| Focal Length | 10-24mm |
| Mount Type | Fujifilm X |
| Format | APS-C / DX |
| Compatible Format(s) | APS-C Sensor |
| Compatible with Teleconverters | No |
| Zoom Ratio | 2.4x |
| Maximum Reproduction Ratio | 1:6.25x at f=24mm |
| Image Stabilization | Yes |
| Aperture Information | |
| Aperture Ring | Yes |
| Maximim Aperture | f/4 |
| Minimum Aperture | f/22 |
| Optical Information | |
| Lens Elements | 14 |
| Lens Groups | 10 |
| Diaphragm Blades | 7 |
| Extra-Low Dispersion Glass Elements | 3 |
| Aspherical Elements | 4 |
| Focus Information | |
| Focus | Autofocus |
| Built-in Focus Motor | Yes |
| Internal Focusing | Yes |
| Minimum Focus Distance | 0.24m |
| Filter Information | |
| Filter Size | 72mm |
| Accepts Filter Type | Screw-on |
| Physical Characteristics | |
| Weather / Dust Sealing | No |
| Mount Material | Metal |
| Dimensions | 87mm x 78 mm |
| Weight | 410g |
| Other Information | |
| Available in Colors | Black |
Lens Construction
MTF Chart
At 10mm focal length, 15 lines/mm:
At 10mm focal length, 45 lines/mm:
At 24mm focal length, 15 lines/mm:
At 24mm focal length, 45 lines/mm:
Image Samples
If I’m not mistaken this is an auto-focus lens.
