Canon TS-E 24mm f/3.5L II

Canon TS-E 24mm f/3.5L II

Lens Summary

Brand: Canon

Also Known As: Canon TS-E 24mm f/3.5L II

Lens Type: Prime Lens

Format: Full Frame / FX

Focus: Manual Focus

Lens Mount: Canon EF

Release Date: 2009-06-01

MSRP Price: $1949

Made in: Japan

Infrared Rating: Mixed

Production Status: In Production

Lens Description: A superb refinement to a true Canon classic, the new TS-E 24mm f/3.5L II offers enhanced functionality and image quality in its most popular tilt-shift focal length. Designed with UD glass to minimize and compensate for chromatic aberrations and a specially coated aspherical element for the highest possible glare-free image quality, this tilt-shift lens features an angle of view of 84° on a full-frame camera.New TS rotation lets users freely combine tilting and shifting within the range of +/- 90° in the direction of movement. The Tilt function has an enhanced range of movement of up to +/- 8.5°, a revolving construction for both portrait and landscape shooting modes, locking, ergonomically-designed and easily operated tilt and shift knobs, uses a circular aperture for beautiful out-of-focus areas, and is constructed using only lead-free glass and has an SWC lens coating that controls ghosting and flare to a far greater degree than earlier coating technologies.


Canon TS-E 24mm f/3.5L II Specifications

Lens Specifications
Lens TypePrime Lens
Focal Length24mm
Mount TypeCanon EF
FormatFull Frame / FX
Compatible Format(s)35mm Film / Full-Frame Digital Sensor Canon (APS-C)
Compatible with TeleconvertersNo
Maximum Reproduction Ratio1:2.9
Image Stabilizer (Image Stabilization)No
Aperture Information
Aperture RingNo
Maximim Aperturef/3.5
Minimum Aperturef/22
Maximum Angle of View (Full frame or larger format)84°
Optical Information
Lens Elements16
Lens Groups11
Diaphragm Blades8
Aspherical Elements3 UD glass elements
Focus Information
FocusManual Focus
Built-in Focus MotorNo
Minimum Focus Distance0.21m
Distance InformationYes
Filter Information
Filter Size82mm
Accepts Filter TypeScrew-on
Physical Characteristics
Weather / Dust SealingNo
Mount MaterialMetal
Dimensions8.89 x 10.67cm
Weight780g
Other Information
Available in ColorsBlack

Lens Construction

Canon TS-E 24mm f/3.5L II Diagrams

MTF Chart

Canon TS-E 24mm f/3.5L II chart
