Lens Summary
Brand: Canon
Also Known As: Canon 24mm f/2.8
Lens Type: Prime Lens
Format: APS-C / DX
Focus: Autofocus
Lens Mount: Canon EF-S
Release Date: 2014-09-15
MSRP Price: $149
Made in: China
Production Status: In Production
Lens Description: Characterized by a truly thin profile, along with an advanced autofocus motor, the EF-S 24mm f/2.8 STM Lens from Canon is a wide-angle prime designed for APS-C-size EOS DSLRs. Providing a 38mm-equivalent focal length, this lens takes on a slightly wider-than-normal perspective to benefit its use in a broad variety of shooting situations. A stepping motor AF system pairs well with cameras featuring the Movie Servo AF mode, where it will deliver fast, smooth, and nearly silent focusing performance that can instantly be manually overridden at any time. When coupled with a sophisticated optical design, this slim, lightweight, and versatile lens is an ideal take-everywhere option.
Canon EF-S 24mm f/2.8 STM Specifications
| Lens Specifications | |
|---|---|
| Lens Type | Prime Lens |
| Focal Length | 24mm |
| Mount Type | Canon EF-S |
| Format | APS-C / DX |
| Compatible Format(s) | APS-C |
| Compatible with Teleconverters | No |
| Maximum Reproduction Ratio | 0.27x |
| Image Stabilizer (Image Stabilization) | No |
| Aperture Information | |
| Aperture Ring | No |
| Maximim Aperture | f/2.8 |
| Minimum Aperture | f/16 |
| Maximum Angle of View (APS-C or smaller format) | 59° 10' |
| Optical Information | |
| Lens Elements | 6 |
| Lens Groups | 5 |
| Diaphragm Blades | 7 (Rounded) |
| Aspherical Elements | 1 |
| Super Spectra Coating | Yes |
| Focus Information | |
| Focus | Autofocus |
| Built-in Focus Motor | Yes |
| Stepper Motor (STM) | Yes |
| Internal Focusing | Yes |
| Minimum Focus Distance | 0.16m |
| Filter Information | |
| Filter Size | 52mm |
| Accepts Filter Type | Screw-on |
| Physical Characteristics | |
| Weather / Dust Sealing | No |
| Mount Material | Metal |
| Dimensions | 68.2 x 22.8mm |
| Weight | 125g |
| Other Information | |
| Available in Colors | Black |
Lens Construction
MTF Chart
Recently we travelled to outback Australia and I purchased an EFS 24mm for my Canon EOS 1200D, along with a tripod and a shutter cable, and lightroom for editing. My first effort for star shots over Uluru was fantastic and the shots were nice and clear using a variety of exposure times. However I have had difficulty getting clearly focussed star shots since, very disappointing. Focussing the lense manually is difficult as I can’t see the stars at night through the viewfinder, I’ve tried focussing on distant objects during the day then being careful not to move the focus before dark, but to no avail. Any advice would be very much appreciated.
Dennis (Melbourne Australia)
